The best bang for the buck
The DVC4 128 works with Daslight Virtual Controller 3 and 4 and the Virtual
3D software packages but is restricted to a maximum of 128 DMX output
channels. This interface can be connected to a PC, or can control your
lighting without a PC using the built in stand-alone memory.
A cheap and easy to use controller featuring :
- 128 DMX output channels in PC mode, 128 DMX output channels in stand-alone mode
- 1x 3pin XLR female socket (output)
- Plug and play USB 2.0 interface with power via the PC's USB socket or via a 5-12v USB mains adapter
- HE10 connector: Trigger scenes through dry contact ports (allows up to
8 trigger actions or 255 if combined in binary and previous/next ports)
- Compatible with any type of DMX 512 fixture
- Internal memory
- 2 buttons to scroll between scenes and 1 button to change the overall brightness of a playing scene
- 2 year guarantee
Software limitations :
- The number of scenes, steps and effects are restricted to 30
- MIDI note control only
- A maximum of 4 Scenes can be played simultaneously.
|
USB
|
type C
|
|
XLR
|
1 x 3-pin
|
|
Housing
|
Plastic
|
|
Buttons
|
3
|
|
Memory
|
50k
|
|
Live Channels by default (XLR)
|
128
|
|
Live Channels max (XLR)
|
512
|
|
Live Art-Net universes
|
Optional
|
|
Live Art-Net universes max
|
30
|
|
DMX IN mode
|
Optional
|
|
Daslight 4
|
Express
|
|
Daslight 5
|
Express
|
|
SA Channels by default
|
128
|
|
SA Channels max
|
512
|
|
SD card memory
|
|
|
Zones
|
1
|
|
Scenes in total
|
99
|
|
Stand alone, buiding with
|
Daslight 4/5
|
